This is an electrical technician's kit which provides the electrical testing needs for installation, plant maintenance and repair of electrical systems.
Kit includes:
● DM autoranging digital multimeter with 11
functions including AC/DC voltage, Capacitance,
Frequency, Resistance, AC/DC current.....etc.
● PMR phase rotation and motor rotation tester.
● non-contact voltage detector
(50 ~1000 Vac) + flashlight.
● High quality carry case.
● 4000-count LCD.
● Auto ranging.
● Voltage, Resistance, Continuity, Diode measurement.
● Frequency, Capacitance, Current measurement.
● Wide range for capacitance test : 0~4000μF.
● Data hold function.
● Low battery indication.
● Over range indication.
● Auto power off.
● With a convenient stand for viewing.
● Compact and lightweight.
|
|
|
|
| AC Voltage |
|
|
|
|
Ranges
|
Resolution
|
Accuracy
|
|
400mV
|
0.1mV
|
±(1.0%rdg+5dgt)
|
|
4V
|
1mV
|
|
40V
|
10mV
|
|
400V
|
100mV
|
|
750V
|
1V
|
| ․Input impedance : 10MΩ |
| DC Voltage |
|
|
|
|
Ranges
|
Resolution
|
Accuracy
|
|
400mV
|
0.1mV
|
±(0.5%rdg+3dgt)
|
|
4V
|
1mV
|
|
40V
|
10mV
|
|
400V
|
100mV
|
|
1000V
|
1V
|
| ․Input impedance : 10MΩ |
| AC mA / µA |
|
|
|
|
Ranges
|
Resolution
|
Accuracy
|
|
400µA
|
0.1μA
|
±(1.0%rdg+6dgt)
|
|
4000µA
|
1μA
|
|
40mA
|
0.01mA
|
|
400mA
|
0.1mA
|
| ․Overload Protection 0.5A/250V fast blow fuse for 400mA |
| DC mA / µA |
|
|
|
|
Ranges
|
Resolution
|
Accuracy
|
|
400µA
|
0.1μA
|
±(1.0%rdg+6dgt)
|
|
4000µA
|
1μA
|
|
40mA
|
0.01mA
|
|
400mA
|
0.1mA
|
| ․Overload Protection 0.5A/250V fast blow fuse for 400mA |
| Resistance |
|
|
|
|
Ranges
|
Resolution
|
Accuracy
|
|
400Ω
|
0.1 Ω
|
±(1.2%rdg+3dgt)
|
|
4kΩ
|
1Ω
|
|
40kΩ
|
10Ω
|
|
400kΩ
|
100Ω
|
|
4MΩ
|
1kΩ
|
|
40MΩ
|
10kΩ
|
±(2.0%rdg+4dgt)
|
| ․Overload Protection 500V DC |
| Capacitance |
|
|
|
|
Ranges
|
Resolution
|
Accuracy
|
|
4 nF
|
1 pF
|
±(3.0%rdg+10dgt)
|
|
40 nF
|
10 pF
|
|
400 nF
|
100 pF
|
|
4 µF
|
1 nF
|
|
40 µF
|
10 nF
|
|
400 µF
|
100 nF
|
|
4 mF
|
1 µF
|
| Frequency |
|
|
|
|
Ranges
|
Resolution
|
Accuracy
|
|
4 kHz
|
1Hz
|
±(0.5%rdg+2dgt)
|
|
40 kHz
|
10 Hz
|
|
100 kHz
|
100 Hz
|
| Continuity |
|
|
|
|
Ranges
|
Audible threshold
|
|
400.0Ω
|
Less than 25Ω
|
| Diode |
|
|
|
|
Ranges
|
Accuracy
|
|
2V
|
±(1.5%rdg+3dgt)
|
| GENERAL |
|
|
|
| Dimensions |
165mm(L) x 82mm(W) x 45mm(D) |
Weight
(battery included) |
Approx. 246g |
| Power source |
1.5V (AAA) battery x 2 |
| Safety standard |
EN 61010-1 CAT III 600V
EN 61010-2-30
EN 61326-1 |
|
|
|
|
| |
SEW0089-Electrician Multimeter Kit
